MEDPC-9300

High Performance Medical Box PC with AMD RyzenTM Embedded V1000

Product Feature

  • Medical Box PC
  • AMD Ryzen Embedded V1605B Processor up to 3.6GHz
  • Supports DDR4 SO-DIMM, Max. 32GB
  • AMD Vega GPU with 8 Compute Units
  • Three Independent 4K Display:1x HDMI 2.0, 1x DisplayPort, 1x USB Type-C
  • 1x USB 3.1 Type-C, 2x USB 3.1 Type-A
  • 1x PCI Express[x8] in Extension Layer(optional)
  • Supports fTPM2.0

Features

1 6

Specifications

System
Processor AMD Ryzen Embedded V1605B Processor
System Memory DDR4 SoDIMM x2, Max. 32GB
Graphics AMD Vega GPU with 8 Compute Units
Expansion Interface PCI Express[x8] x1
Storage Disk Drive 2.5” SATA SSD x1
Security fTPM2.0
Wireless
Communication
802.11ac/a/b/g/n(optional), Bluetooth(optional)
Power Requirement DC 12~24V
OS Support Win 10 IoT Enterprise 64-bit / Linux Ubuntu 64-bit
Display
Video Out 1x HDMI 2.0, 1x Display Port 1.4, 1x USB Type-C
Display Up to 3840 x 2160 resolution, at 60Hz
HDMI Up to 3840 x 2160 resolution, at 60Hz
I/O
USB 2x USB 3.1 Type-A, 1x USB 3.1 Type-C, 2x USB2.0
Serial Port 2x RS-232
Audio Mic, Line-out
LAN 2x Gigabit Ethernet
Audio Jack Mic, Line-out
Mechanical and Environmental
Operating Temperature 0°C ~ 40°C(32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C(-4°F ~ 140°F)
Dimension 197 x 197 x 59.5 mm for main layer
197 x 197 x 44 mm for extension layers
Package Size 300 x 280 x 95 mm
Gross weight 3.3 kg (7.25 lb) in the single layer,
4.0 kg (7.25 lb) in two layer
Net Weight 2.5 kg in the single layer,
3.7 kg in two layers
Certifications CE: EN 60601-1-2:2015(V4.0),
EN 60601-1:2006/A1:2013/A12:2014 (V3.1)
FCC: Part 18 Class B
UL: ANSI/AAMI ES60601-1:2012 (V3.1)
cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1)
