UPower Pro-43

4-Slot Hot Swappable Battery Medical Power Bank

Product Feature

  • Compatible with onyx XL battery and XXL battery (not for STD battery)
  • Two mode for user
    - Normal mode : max capacity – 90W/520Wh (with XXL battery)
    - Power mode : max output – 90W/260Wh + 65W/260Wh (with XXL battery)
  • 3x DC output
  • Selectable voltage for each DC-out (12V / 15V / 19V / 24V)
  • Built-in wifi chip for remote monitor directly
  • LED indicator, clearly reveal recharge/discharge status

Features

Specifications

Main Specifications
  UP-43P (Power Bank) UP-43L (Charger only)
Output Voltage DC out x3
Selectable voltage for each port.
12/15/19/24V (only one voltage at
the same time for one port)
N/A
Output Capacity Normal mode : share 90W with
2 port
Power mode : 90W for ch1; 65W
for ch2
Medical 45W AC output (optional)
N/A
Charge Time 6hrs for XL battery; 8hrs for XXL
battery
(no charge when power output)
Normal Charge: 8hrs for XL
battery; 10hrs
for XXL battery
Fast Charge: 3.5hrs for XL
Function Key Power Mode Button :
Normal(max capacity) Power
mode(max output)
Charge Button :
Power output charger
Fast Charge Button : normal
charge fast charge
Extend Function Adaptor holder (optional)
Cart mount bracket (optional)
UP board (optional)
45W Medical AC inverter (optional)
Adaptor holder (optional)
Cart mount bracket (optional)
Safety

Supports protection from over-voltage (input), over-current

(input and output), short circuit, over-charge.

Certification CE, FCC, IEC60601-1
Mechanical and Environmental
Architecture ABS + PC
Color White
Dimension 255(L) x 160(W) x 213(H) mm
Net Weight 1kg (1.47 lbs) (w/o battery)
Operating Temperature 0°C ~ 35°C(32°F ~ 95°F)
Storage Temperature -20°C ~ 60°C(-4°F ~ 140°F)
Storage Humidity 10%~95%@35°C, non-condensing
Power Supply Specification
Input Voltage 100-240V AC @50-60 Hz
Output Power 24V / 250W max
