• MD101 MD101

MD101

10.1” Rugged Medical Tablet

Product Feature

  • Intel® Cherry Trail processor
  • Slim & lightweight design for clinical mobility
  • Long battery life for intensive care services
  • Standard USB Type-A for easy connection to medical devices
  • IP54 certified & 3 feet drop resistant
  • ORION client compatible
  • VESA mounting via adapter
  • EN60601-1 & UL60601-1 Certified
  • Ergonomic design adapted for portable and cart use
  • Windows 10 and Android 6.0 available
  • 3-foot
  • IP54
  • Dual SCRs
  • TAG RFID
  • Dual LTE
  • Swap
  • Automotive
  • EN/UL 60601-1
  • Sunlight Readable
  • Touch
  • light
  • wifi
  • battert time
  • Alarm
  • bluetooth
  • size

Features

1 6

Specifications

Main Specifications
Processor Intel® Cherry Trail QC Processor Z8350 1.44 GHz
System Memory 2 / 4 GB
OS Support Microsoft® Windows 10 IOT LTS/An Android 6.0
Storage eMMC 64 /128 GB
Wireless Communication 802.11 a/b/g/n+BT 4.0
Gyroscope Sensor Bosch BMG 160
Camera 2 MP (Front) / 8 MP (Rear)
Touchscreen Projected Capacitive Touchscreen , w/Gorilla Glass
Accelerometer Sensor Bosch BMC150
Ambient Light Sensor Capella CM3218
Power Button x1
Volume Keys x2
Speakers 3 W x2
Internal Mic x1
Alarm Light x1 (Optional)
Power Requirement DC 15 V
Display
Display Size 10.1” 16:10 Wide Screen LED Panel
Resolution FHD 1920 x 1200
Max. Colors 16.7 M
Contrast Ratio 800:1
Luminance (cd/m2) 300 nits
I/O
USB USB 3.0 (Type-A) x1
Audio Out / Mic In 3.5 mm Combo Audio Jack x1 N/A
Video Out Micro HDMI x1 (Optional)
DC-In x1
Battery Pack
Battery Type Polymer
Battery Capacity 4090mAh (46.62 Wh
Battery Run Time Approx. 8 hrs
Mechanical and Environmental
VESA VESA 75 via cradle
Operating Temperature -10° C ~ 55° C (14° F ~ 131° F)
Storage Temperature -20° C ~ 60° C (-4° F ~ 140° F)
Storage Humidity 10%~95%@35°C, non-condensing
Dimension 260 (W) x 186 (H) x 23 (D) mm
Net Weight Approx. 1 kg
Certifications CE: EN 60601-1-2:2015(V4.0),
EN 60601- 1:2006/A1:2013(V3.1)
EN 300 328(V2.1.1), EN 301 893 (V2.1.1)
FCC: Part 18 Class B, Part 15 C/E
UL: ANSI/AAMI ES60601-1:2012 (V3.1)
cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1)







Downloadable Contents
