MEDPC-9200

High Performance Medical Box PC with Intel ® 6th Generation Core™ iSeries

Product Feature

  • Medical Box PC
  • Intel® 6/7th Generation Core i Processor
  • Supports DDR4 up to 32GB
  • Extension area: PCI-Express [x1] x 1(optional)
  • Two Independent , Display: DP/HDMI
  • Supports TPM 2.0
  • Modularize Design
  • Support Inte Modivus AI card
  • AI
  • Isolated

Features

1 6

Specifications

Main Specifications
Processor Intel® 7th/6th Generation Core™ i7/i5/i3
System Memory Supports Dual Channel DDR4 SODIMM up to 32 GB
OS Support Windows® 7, Windows® 8,Windows®10, Linux®
Storage Disk Drive 2.5” SATA SSD x 1
Extension area PCI-Express [x1] x 1
Security TPM 2.0
Power Requirement DC 12V
I/O
USB USB 3.0 x 4 , USB 2.0 x2
Serial Port RS232 x 2
Ethernet Gigabit LAN x 2
Video Out Display Port x 1 (Support up to 1920 x 1200 @60 Hz) ,
HDMI 1.4 x 1
Audio Mic-in, Line-out
Mechanical and Environmental
Operating Temperature 0°C ~ 40°C(32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C(-4°F ~ 140°F)
Dimension 197 x 197 x 59.5 mm for main layer
197 x 197 x 44 mm for extension layers
Package Size 300 x 280 x 95 mm
Gross weight 3.3 kg (7.25 lb) in the single layer,
4.0 kg (7.25 lb) in two layer
Net Weight 2.5 kg in the single layer,
3.7 kg in two layers
Certifications CE: EN 60601-1-2:2015(V4.0),
EN 60601-1:2006/A1:2013/A12:2014 (V3.1)
FCC: Part 18 Class B
UL: ANSI/AAMI ES60601-1:2012 (V3.1)
cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1)
