Dual GPU card Medical AI Box PC with Intel 12th Gen Core i9 CPU

Product Feature

  • Intel® Core™ i9-12900E Processor 30M Cache, up to 5.00 GHz
  • Support 4 x DDR4 3200 288 pin Long-DIMM up to 128GB
  • Optional 7" Front Screen with P-Cap Touch
  • Support front dual USB 3.0
  • Support GPIO and Remote Power Switch design for embedded use
  • Support Dual Nvidia RTX A6000 cards and additional capture card installation
  • Support 4 x PCIe Gen4 Slots for high end graphic card and capture card integration
  • Support Medical Grade 1500W PSU for Dual GPU Card and 700W PSU for Single GPU card
  • AI



Main Specifications
Processor Intel® Core™ i9-12900E Processor 30M Cache, up to 5.00 GHz
Chipset Intel W680
System Memory DDR4 3200 DIMM x 4 up to 128GB
Front Scree(Optional) 7” LED Panel with P-Cap Touch
Storage Disk Drive 2.5” SATA SSD x 2, M.2 2280 NVMe SSD x 1
TPM 2.0
Speaker (Optional) 5W x 2
OS Support Windows® 10 and 11, Linux (optional)
USB USB 3.2 Gen 2 Type A x 5, USB Gen 2 20G Type C x 1
Ethernet GigaLAN x 1, 2.5G LAN x 2
Video Out HDMI 2.0 x 1, DP 1.4 x 1, VGA x1
Audio Line-in x 1, Mic-in x 1, Line-out x 1
Series Ports RS232 x 2
Function I/O Remote power switch x 1 (Optional)
Grounding pin x 1
Power AC input
Front I/O USB 3.0 x 2, Power Button x 1
Expansion I/O 2 x PCIe Gen4 Slots (PCIE1/PCIE3:single at x16(PCIE1);
dual at x8 (PCIE1) / x8 (PCIE3)) with x16 connector
PCIe [x 4] x 2
M.2 2230 E Key x 1
M.2 2280 M Key [PCIe x 4] x 1

Mechanical and Environmental

Power Consumption 100V to 240V AC Input , 700W or 1500W
Operating Temperature 0°C ~ 35°C(32°F ~ 95°F)
Storage Temperature -20°C ~ 60°C(-4°F ~ 140°F)
Dimension 420 x 169 x 409 mm
Package Size 630 x 310 x 565 mm
Gross Weight 12kg
Net Weight 11kg
Certifications CE: EN 60601-1-2:2015(V4.0),
EN 60601-1:2006/A1:2013/A12:2014 (V3.1)
FCC: Part 18 Class B
UL: ANSI/AAMI ES60601-1:2012 (V3.1)
cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1)
